Albio 127C Super Thermo is a new opening tilt and turn system with special polyamides, which enables the creation of exceptionally stylish frames without visible sashes
Technical Characteristics
- Aluminum Alloy:EN AW 6060Τ6, EN 15088:2005
- Powder coating:According to the European standard Qualicoat
- Anodising:According to the European standard Qualanod
- Tolerance:EN 12020-2
- Gaskets:EPDM / EPDM Foam
- Chamber:Compatible with multiple locking mechanisms
- Glazing Thickness:35mm
- Thermal- Break:34mm (PA 6.6, 25%GF)
- Air Permeability:Specimen dimensions: 1.40m X 1.40m : Class 4 (EN 12207:1999-11)
- Water Tightness: Specimen dimensions: 1.40m X 1.40m : Class Ε900 (EN 12208:1999-11)
- Frame dimensions: Width 76,5mm, height 72mm
- Sash dimensions: Width 77,3mm, height 53,3mm
- Resistance to wind load: Specimen dimensions: 1.40m X 1.40m : Class C4/B4 (EN 12210:1999-11/AC:2002-08)
APPLICATIONS:
- Doors, windows and shop fronts. Fixed, tilt & turn etc.
