The series Albio 109C Super Thermo is the leading and most advanced range of Exalco in Thermal insulation.The extremely low thermal transmittance coefficiency has been achieved by using wider polyamide profiles (34mm), the insertion of new high insulation material and the use of new gaskets. The excellent air permeability test results and the ability of using up to 50mm thick glazing units offer high sound insulation. The system includes high security mechanism, known as perimeter multi-locking mechanism.Uses special insulating material and high amplitude polyamides achieving high thermal performance of European standards.Uses special insulating material and high amplitude polyamides achieving high thermal performance of European standards.
Technical Characteristics
- Aluminum Alloy: EN AW 6060Τ6, EN 15088:2005
- Powder coating: According to the European standard Qualicoat
- Anodising: According to the European standard Qualanod
- Tolerance: EN 12020-2
- Gaskets: EPDM / EPDM Foam
- Chamber: Compatible with multiple locking mechanisms
- Glazing Thickness:26-64mm
- Thermal- Break: 34mm (PA 6.6, 25%GF)
- Air Permeability: Double sash window 1.40m X 2.20m: Class 4 (EN 1026:2000 / EN 12207:2000)
- Thermal transmittance coefficient:1.5 – 2.0 W/(m2K) (EN 10077-2:2003-10)
- Water Tightness: Double sash window 1.40m X 2.20m: Class Ε750 (EN 1027:2000 / EN 12208:2000)
- Frame dimensions: Width 82.7-100mm, height 53.1-70 mm
- Sash dimensions: Width 85.7mm, height 74.3-96.1mm
- Resistance to wind load: Double sash window 1.40m X 2.20m: Class C4 (EN 12211:2000 / EN 12210:2000)
Applications :
- Doors, windows and shop fronts. Fixed, tilt & turn etc.
